AURORA D - DOUBLE DISC COMBINED SEEDER

AURORA D - DOUBLE DISC COMBINED SEEDER

AURORA D the mechanical double-disc seeder is used in fields with a lot of stubble, as well as for planting on flat and sloping areas. The seeder has double-row legs, which allows sowing in 2 rows. Disc feet are like ax feet, opening up furrows to push soil aside. The height of the ridge increases as the groove widens. Thanks to these properties, double disc feet can be used in any climate and soil conditions.

Standard model kit:

Double hydraulic marker

Vertical harrow

Hydraulic adjustment of sowing depth

Seed level indicator

Seed mixer

Ripper

Reflective stickers.

TECHNICAL SPECIFICATIONS

TECHNICAL SPECIFICATIONS

UNIT

AURORA D - DOUBLE DISC COMBINED SEEDER

AURORA S19

AURORA  S23

AURORA S27

AURORA S31

AURORA S39

AURORA S47

Number of legs

pcs

19

23

27

31

39

47

Row spacing

mm

130

130

130

130

130

130

Working width

mm

2500

3000

3500

4000

5000

6000

Width

mm

2735

3235

3735

4235

5350

6350

Height

mm

1500

1500

1500

1500

1500

1500

Seed hopper volume

l

465

555

645

735

915

1095

Fertilizer tank volume

l

310

375

405

430

485

540

Tank volume without fertilizers

l

755

955

1155

1355

1755

2155

Tire size



600 -16

600 -16

600 -16

600 -16

10.0 -75/13

10.0 -75/13

Working speed

km/h

5 - 8.

5 - 8.

5 - 8.

5 - 8.

5 - 8.

5 - 8.

Weight

kg

850

1000

1180

1290

1580

1860

Tractor power

hp

70+

80+

100+

110+

130+

160+
