AURORA C - CHISEL TYPE SEEDER

AURORA C the mechanical seeder is designed to distribute seeds and fertilizer at the desired depth. To make the legs of the spring chisel, material 23 mm thick is used; seed sowing is created using a special mold. The legs of the spring chisel are arranged in 3 rows, as on axing machines. Thus, the stubble does not remain on the field surface. The chisel type leg is practical to use for many soil conditions.

Standard model kit:

Chisel leg type

Double hydraulic marker

Vertical harrow

Seed level indicator

Seed mixer

Reflective stickers

Hydraulic adjustment of sowing depth/

TECHNICAL SPECIFICATIONS

TECHNICAL SPECIFICATIONS

UNIT

AURORA C - CHISEL TYPE SEEDER

AURORA C21

AURORA C25

AURORA C29

AURORA C33

Number of legs

pcs

21

25

29

33

Row spacing

mm

120

120

120

120

Working width

mm

2500

2000

3500

4000

Width

mm

2735

3235

3735

4235

Height

mm

1500

1500

1500

1500

Seed hopper volume

l

465

555

645

735

Fertilizer hopper volume

l

310

375

405

430

Hopper volume without fertilizers

l

755

955

1155

1355

Tire size



500 -12

500 -12

500 -12

600 -16

Working speed

km/h

5 - 8.

5 - 8.

5 - 8.

5 - 8.

Weight

kg

820

970

1150

1260

Tractor power

hp

70+

80+

100+

110+
