AURORA A - AXE TYPE SEEDER

AURORA A the mechanical anchor seeder provides control of seeding and fertilizer for the desired depth. The planting depth can be increased due to additional load. A fertilizer and seed hose passes between the ribs and lowers them into the soil. The seed bed is well prepared for sowing. In the disk-spring type, the paw does not move upward when colliding with obstacles (stone clods, etc.), since the ax paw is mounted on the chassis. A worn ax should be replaced. The end spring legs are cast and sealed on both sides with plate ribs.

Standard model kit:

Double hydraulic marker

Mechanical adjustment of sowing depth

Vertical harrow

Seed level indicator

Seed mixer

Reflective stickers.

TECHNICAL SPECIFICATIONS

TECHNICAL SPECIFICATIONS

UNIT

AURORA A - AXE TYPE SEEDER

AURORA  A16

AURORA A18

AURORA A20

AURORA A22

AURORA A24

AURORA A28

AURORA A32

Number of legs

pcs

16

18

20

22

24

28

32

Row spacing

mm

125

125

125

125

125

125

125

Working width

mm

2000

2250

2500

2750

3000

3500

4000

Width

mm

2235

2485

2735

2985

3135

3735

4235

Height

mm

1500

1500

1500

1500

1500

1500

1500

Seed hopper volume

l

265

305

345

365

405

445

470

Fertilizer tank volume

l

245

275

310

345

375

405

430

Tank volume without fertilizers

l

525

590

655

720

790

950

1025

Size of tire



500 -12

500 -12

500 -12

600 -16

600 -16

600 -16

600 -16

Working speed

km/h

5 - 8.

5 - 8.

5 - 8.

5 - 8.

5 - 8.

5 - 8.

5 - 8.

Weight

kg

720

750

770

790

815

1050

1150

Tractor power

hp

40 - 50

50 - 60

60 - 70

70 - 80

80 - 90

100 - 110

110 - 120
