MANGUS P - CHISEL PLOUGH

Chısel plough of heavy type - designed for deep loosening of soil to a depth of 40-55 cm, compacted, waterproof soil layer, destruction of plow sole without turnover of the layer and without damaging the stubble, deepening of the arable horizon. It is used to improve the water-air environment of the root layer of the soil, which prevents the development of soil erosion and promotes the accumulation of moisture and increase crop yields. The special design of legs made of high carbon steel allows breaking and penetrating the toughest layers of soil, and the toothed roller is designed for crushing and leveling the surface layer of soil.

TECHNICAL SPECIFICATIONS

TECHNICAL SPECIFICATIONS

UNIT

MANGUS P - CHISEL PLOUGH

MANGUS P5

MANGUS P7

MANGUS P9

MANGUS P11

MANGUS P13

Legs quantity

pcs

5

7

9

11

13

Distance Between Legs

mm

250

250

250

250

250

Weight

kg

285

425

550

680

830

Total Width

mm

1500

2000

2500

3000

3500

Chassis Profile Sizes

mm

100*100*6

100*100*6

100*100*8

100*100*8

100*100*8

Working Width

mm

1200

1700

2200

2700

3200

Power

hp

50-60

70-80

80-90

90-100

100-120
