MANGUS - SPRING CHISEL PLOUGH

Spring-type deep harrow - designed for deep loosening of soil to a depth of 40-55 cm, destruction of plow sole without turnover of the layer and without damage to the stubble, deepening of the arable horizon. is used to improve the water-air environment of the root layer of the soil, which prevents the development of soil erosion and contributes to the accumulation of moisture and increase crop yields. In case of hitting hard and stony rocks independent tines of spring type perfectly bypasses the obstacle ensuring the safety of the machine, and the roller is designed for crushing and leveling the surface layer of soil and adjusting the depth of cultivation with the help of hydraulic depth control system.

TECHNICAL SPECIFICATIONS

TECHNICAL SPECIFICATIONS

UNIT

MANGUS - SPRING CHISEL PLOUGH

MANGUS 5

MANGUS 7

MANGUS 9

MANGUS 11

MANGUS 13

MANGUS M5

MANGUS M7

MANGUS M9

MANGUS M11

MANGUS M13

Description



5 Legs

7 Legs

9 Legs

11 Legs

13 Legs

5 Legs (with roller)

7 Legs (with roller)

9 Legs (with roller)

11 Legs (with roller)

13 Legs (with roller)

Power

hp

50-70

70-100

90-120

100-130

110-140

50-70

70-100

90-120

100-130

110-140

Working Width

mm

1750

2400

3100

3800

4500

1750

2400

3100

3800

4500

Height

mm

750

750

750

750

750

750

750

750

750

750

Operating Depth

mm

400-450

400-450

400-450

400-450

400-450

400-450

400-450

400-450

400-450

400-450

Weight

kg

520

580

740

890

1010

670

780

950

1120

1250
