HARES - X-TYPE DISK HARROW

The disc harrow is used for seedbed preparation, chopping crop residues, cutting soil layers, weed control, soil cultivation after harvesting thick-stemmed crops or fertilizer incorporation into the soil. The X-type design of the harrow allows to cultivate the soil to a depth of up to 20 cm, the presence of two rows of disks provides active soil crumbling, and thanks to the cleaning device the soil sprouts evenly from the concave side of the discs, providing an even soil surface on the cultivated field, as well as aeration and balance of water and temperature environment in the soil. If the customer wishes, it is possible to install a hydraulic system for sliding (opening-closing) the x-type batteries.

TECHNICAL SPECIFICATIONS

TECHNICAL SPECIFICATIONS

UNIT

HARES - X-TYPE DISK HARROW

HARES 20

HARES 24

HARES 28

HARES 32

HARES 36

Disc Quantity

pcs

20

24

28

32

36

Disk Diameter

mm

510

510

510

510

510

Interval between discs

mm

180

180

180

180

180

Bed quantity

pcs

8

8

8

8

8

Power

hp

50-60

60-70

70-80

80-100

100-120

Working Width

mm

1900

2280

2660

3040

3420

Operating Depth

mm

200

200

200

200

200

Weight

kg

650

700

790

840

880
