BARS - DISC HARROW

Compact disc harrows are suitable for shallow and compact cultivation of mixed soils. The disc harrow with rubber wedges, widely used in stubble cultivation and seed bed preparation, ensures crushing and mixing of plant residues with the soil. Rubber wedges with a diameter of 40 mm, used in support joints, prevent damage to the discs by springing the discs in a vertical direction, allowing the machine to work quickly and without hesitation, even in difficult soil cultivation conditions. The reinforced chassis of the BARS model is suitable for use in difficult conditions. Equipped with durable and strong roller bearings that do not require maintenance or lubrication. All disk legs are attached to the battery independently of each other using special protective rubber bands. Rubber wedges with a diameter of 40 mm, used in support joints, prevent damage to the discs by springing the discs in a vertical direction, allowing the machine to work quickly and without hesitation, even in difficult soil cultivation conditions. The working depth is easily adjusted using a roller. The height of the rollers can be adjusted mechanically or hydraulically.

TECHNICAL SPECIFICATIONS

TECHNICAL SPECIFICATIONS

UNIT

BARS - DISC HARROW

BARS 20

BARS 24

BARS 28

BARS 32

Number of disks

adet

20

24

28

32

Working width

cm

250

300

350

400

Height 56

cm

145

145

145

145

Height 61

cm

155

155

155

150

Road width

mm

280

330

380

430

Weight 56 (cm)

kg

1350-1400

1500-1550

1650-1700

1800-1850

Weight 61 (cm)

kg

1450-1500

1620-1670

1790-1840

1960-2010

Tractor power

hp

70-90

90-110

110-130

130-150
