XEON LIGHT - LIGHTWEIGHT TRAILED DISC HARROW

XEON LIGHT - LIGHTWEIGHT TRAILED DISC HARROW

The XEON LIGHT lıghtweıght traıled dısc harrow is designed for cutting and crushing plant residues (sunflower, corn, wheat, etc.) and weeds after harvesting. XEON LIGHT prepares the soil directly for sowing without the use of other agricultural equipment, processes without clods in dry months when plows cannot cope after harvest and when processing soil with high humidity. The leaf spring suspension minimizes bearing and disc failure, creating a flexible design that adapts to uneven field surfaces and road conditions during operation. The 25-degree blade angle and heavy-duty chassis provide maximum working depth. Scrapers on each disc clean the discs during tillage, preventing the formation of debris. The chassis height is 100 cm, the distance between the discs is 18 cm, and the space between the front and rear discs is designed to be wide. Disc harrows are moved using a hydraulic system, preventing wind and water erosion and at the same time damaging the stubble. The wheel mechanism allows you to effectively adjust the working depth.

TECHNICAL SPECIFICATIONS

TECHNICAL SPECIFICATIONS

UNIT

XEON LIGHT - LIGHTWEIGHT TRAILED DISC HARROW

XEON LIGHT 28

XEON LIGHT 32

XEON LIGHT 36

XEON LIGHT 40

Number of disks

pcs

28

32

36

40

Working width

сm

245

285

325

365

Disc diameter

mm

510

510

510

510

Disc distance

mm

180

180

180

180

Main frame

mm

100х100х6

100х100х6

100х100х6

100х100х6

Weight

kg

1250

1474

1530

1590

Tractor power

hp

60-75

75-90

90-110

110-130
