XEON FOLD - HEAVY TYPE FOLDING DISC HARROW

XEON FOLD - HEAVY TYPE FOLDING DISC HARROW

The XEON FOLD heavy type foldıng dısc harrow is designed for cutting and crushing plant residues (sunflower, corn, wheat, etc.) and weeds after harvesting. XEON FOLD prepares the soil directly for sowing without the use of other agricultural equipment, processes without clods in dry months when plows cannot cope after harvest and when processing soil with high humidity. The leaf spring suspension minimizes bearing and disc failure, creating a flexible design that adapts to uneven field surfaces and road conditions during operation. The 25-degree blade angle and heavy-duty chassis provide maximum working depth. Scrapers on each disc clean the discs during tillage, preventing the formation of debris. Disc harrows are moved using a hydraulic system, preventing wind and water erosion and at the same time damaging the stubble. The wheel mechanism allows you to effectively adjust the working depth.

TECHNICAL SPECIFICATIONS

TECHNICAL SPECIFICATIONS

UNIT

XEON FOLD - HEAVY TYPE FOLDING DISC HARROW

XEON FOLD 44

XEON FOLD 48

XEON FOLD 48

XEON FOLD 52

XEON FOLD 56

Number of disks

pcs

44

48

48

52

56

Working width

mm

4050

4450

5320

5780

6240

Disc diameter

mm

510

510

610

610

610

Disc distance

mm

180

180

230

230

230

Main frame

mm

100х200х5

100х200х5

100х200х8

100х200х8

100х200х8

Weight

kg

1215

1300

3550

3690

3830

Tractor power

hp

100-110

110-120

190-210

210-230

230-250
