XEON - TRAILED DISC HARROW WITH HYDRAULIC LIFT

XEON - TRAILED DISC HARROW WITH HYDRAULIC LIFT

XEON trailed disc harrow with hydraulic lift is designed for cutting and crushing plant residues (sunflower, corn, wheat, etc.) and weeds after harvesting. XEON prepares the soil directly for sowing without the use of other agricultural equipment, processes without clods in dry months when plows cannot cope after harvest and when processing soil with high humidity. The leaf spring suspension minimizes bearing and disc failure, creating a flexible design that adapts to uneven field surfaces and road conditions during operation. The 25-degree blade angle and heavy-duty chassis provide maximum working depth. Scrapers on each disc clean the discs during tillage, preventing the formation of debris. Disc harrows are moved using a hydraulic system, preventing wind and water erosion and at the same time damaging the stubble. The wheel mechanism allows you to effectively adjust the working depth.

TECHNICAL SPECIFICATIONS

TECHNICAL SPECIFICATIONS

UNIT

XEON - TRAILED DISC HARROW WITH HYDRAULIC LIFT

XEON 24

XEON 28

XEON 30

XEON 34

XEON 36

Number of disks

pcs

24

28

30

34

36

Working width

mm

2530

2990

3220

3680

3910

Disc diameter

mm

660

660

660

660

660

Disc distance

mm

230

230

230

230

230

Main frame

mm

100х200х6

100х200х6

100х200х6

100х200х6

100х200х6

Weight

kg

2030

2250

2370

2610

2730

Tractor power

hp

90-100

110-120

120-130

140-150

150-160
